SALINE FLUID STORAGE SOLUTION
ESG Focused, Reduced Surface Impact & Cost Effective
NEW SOLUTION OVERCOMES CHALLENGES
Freshwater conservation and the environmental impacts of responsibly managing saline fluid as a sustainable solution requires safe, environmentally sensitive long-term storage solutions. Current available saline storage infrastructure has proven to have its challenges with respect to containment integrity, long-term reliability, and cost certainties.
Western Engineered Containment and Bay Tank and Vessel of Canada are building OGCBC and AER compliant 50,000 m3 produced water storage tanks. The tanks are ESG focussed, will result in a 75% reduction in surface impact when compared to Engineered Containment Ponds and cost effective.
ADVANTAGES
- Up to a 75% reduction in footprint considerably reducing land disturbance
- Lowers risk to potential failure
- Increased access to complete inspections and maintenance to ensure containment integrity is never lost
- The ability to inexpensively recycle the entire asset should reclamation occur – SALVAGED STEEL TO SCRAP OFFSET VIRTUALLY ALL COSTS OF RECLAMATION
- Ability to have multiple assets connected into the same fluid management system offering unlimited scalability.
- Safely and easily cleaned, inspected, and repaired
- Low double-walled connections eliminate submersible pumps
- Flexibility in the construction schedule, seasonal impacts are negligible in caparison to pond or C-Ring farm development
- Enhanced instrumentation available – water quality, sampling, CCTV, remote operation, etc.
- Significant increase in distance to groundwater tables over pond developments
- Continuous, monitored interstitial space for true double-walled containment
THE BAYTANK SOLUTION
As a solution, we are pleased to offer the BayTank, an innovative design cornerstoned by a decades-old storage solution and integrating cutting-edge Engineered Containment System (ECS). The BayTank solution provides the industry with the safest, smallest environmental footprint and long-term saline fluid storage system in the industry today.
The BayTank consists of an API 650 steel welded storage tank as secondary containment with a seamless PRECIDIUM™ ECS™ spray-applied lining system as primary containment. This integration creates the largest available above-ground saline storage system in the industry. Designed to meet the intent and technical requirements of AER Directive 055 and BC OGC for secondary containment, and saline fluid storage requirements. This proprietary design allows the BayTank to specifically meet our client’s individual facility needs offering any volume up to 65,000 cubic meters.
For more information on Saline Fluid Storage Solution, please contact:
Bay Tank and Vessel Canada
[email protected] or 403-817-5783
