Water-inflated dams are quickly and easily deployed, filled with any available source of water and are an environmentally friendly option were overall impact to surrounding areas is a concern.
NCS double and triple Ark Water Barrier are fully customizable and come in two standard models as well; Double Dams or Triple Dams are reusable season to season or project by project, providing extremely flexible design /layout full contact configurations, do no substrate damage, and are suitable for worksites performing dewatering or flood protection in waters up to 6’ (1.8m) deep.
The Double Dam features one internal stabilizing panels acting as a baffle to provide safety and stability for all sizes from 3’ (0.9m) to up to 8’ (2.4m) high.
The Triple Dam features two internal stabilizing panels acting as baffles to provide safety and stability for all sizes from 3’ (0.9m) to up to 8’ (2.4m) high.
The NCS Environmental Solutions Ltd. secondary containment system consists of overlapping High Density Polyethylene (HDPE) panels. The panels are free-standing and come in two shapes; straight panels that measure 1.0m x1.0m x1.0m and 45° rounded corner panels that measure 0.96m x 1.0m x 1.0m.
This unique design allows for users to assemble the panels in a variety of configurations appropriate for their containment area. As a 2C Enviro Inc distributor NCS Environmental Solutions has the added protection of the engineered and patented design. for the system (application no.3,033,434 and reference 75605-1)
The containment systems is lined with a poly liner so In the event of a spill from the above ground storage tanks, or equipment housed within the containment system effectively contains harmful fluids to prevent seepage to underground water sources and damage to the environment. When the system was reviewed with respect to the following regulations: Alberta ERCB Directive 55 “Storage Requirements for the Upstream Petroleum Industry”. Saskatchewan Directive S-01 “Upstream Petroleum Industry Storage Standards”. British Columbia “Oil and Gas Activity Application Manual”.
The secondary containment panels have been analyzed to resist overturning and localized bending failure under hydrostatic fluid loads. The panel deformation was calculated and measured to be within acceptable limits to prevent spillage and maintain performance over several days of fluid containment.
With NCS Environmental Solutions stocks materials & equipment in NCS locations across Canada, we offer rapid response in the event of an emergency such as fire water supply, spill containment, water diversion & flood mitigation. NCS Environmental Products offer complete services, for installation, filling demobilization & recertification & testing of Aqua Barrier dams & flex hose as well as a complete line of sales & rental systems, whenever & wherever you need it.
Getting ready with a prepared plan or experiencing an emergency right now?
Our team understands the benefits of executing a well-prepared plan & the magnitude of emergency situations & responds accordingly. We work in a responsive & safe manner to mobilize manpower, pipe, pumps, & support equipment.
Emergency flood pumping services normally calls for flood mitigation & emergency pumping. We prepare, supply, & install various pumps & lengths of drainage lines so water can be moved safely & effectively incorporating filtration if required or erosion control methods.
Need additional pump or pipe during an emergency? NCS Fluid Handling Systems team can provide that.
